• Option: TRL system FA003856000

Series:

Rogue

Model:

ROGUE AIR 27.5

Size:

27.5"

Area of ​​application:

Downhill / Freeride / All Mountain

Version:

Ahead, tapered (threadless)

Spring travel:

160mm

Suspension:

Right oil cartridge / left air chamber

Preload:

Air pressure, adjustable

Pressure level:

Hydraulic, lockable

Rebound:

Hydraulic, adjustable

Steerer:

1.5" tapered - 260 mm x Ahead / pressed in 7050 aluminum

Bridge:

Aluminum, powder-coated

Standpipe:

34 mm, 7050 aluminum, hard anodized

Dip tube:

Magnesium

Brake type:

Disc brake

Brake mount:

Post Mount

Max. Brake disc diameter:

203mm

Axis standard:

15mm

Weight:

Approx. 2.02kg

Dimensions:

Installation height 555 mm, caster 43 mm

Axle width:

100mm
